Metal Polarizing Microscopes Laboratory Binocular Microscope , Rohs A15.1017

Name: Metal Polarizing Microscopes Laboratory Binocular Microscope Rohs A151017
Brand: CNOEC, OPTO-EDU
Price: 1 USD

China Metal Polarizing Microscopes Laboratory Binocular Microscope , Rohs A15.1017 wholesale

Place of Origin : China

Brand Name : CNOEC, OPTO-EDU

Certification : CE|Rohs

Model Number : A15.1017

MOQ : 1 pc

Price : Negotiation

Packaging Details : Carton Packing, For Export Transportation

Delivery Time : 5~20 Days

Payment Terms : T/T, West Union, Paypal

Supply Ability : 5000 pcs/ Month

application : metal|silicon wafers

Drawtube : Binocular|Trinocular

Illumination : Halogen Lamp

magnification : 40X - 400X

Theory : Polarizing Light Microscope

Contact Now

Metal Polarizing Microscopes Laboratory Binocular Microscope , Rohs A15.1017

Description:

The polarized light microscope is designed to observe and photograph specimens that are visible primarily due to their optically anisotropic character. Polarized light microscopes have a high degree of sensitivity and can be utilized for both quantitative and qualitative studies targeted at a wide range of anisotropic specimens. Qualitative polarizing microscopy is very popular in practice, with numerous volumes dedicated to the subject. In contrast, the quantitative aspects of polarized light microscopy, which is primarily employed in crystallography, represent a far more difficult subject that is usually restricted to geologists, mineralogists, and chemists.

Specifications:

Specification A15.1017		A	B
Head	Binocular Head	●
	Trinocular Head		●
Eyepiece	WF10x/18
Objective	Infinity Plan Achromatic Objectives 4×/0.1/∞/- WD25.4mm
	Infinity Plan Achromatic Objectives 10×/0.25/∞/- WD11.0mm
	Infinity Plan Achromatic Objectives 40×/0.60/∞/0 WD3.7mm
Stage	Double layer mechanical stage150×140mm/75×50mm
Nosepiece	Quadruple Nosepiece
Focusing	Coaxial Fine & Coarse Adjustment
Illumination	Kohler Illumination, Epi-illuminator with iris aperture diaphragm and iris field diaphragm, 6V/20W Halogen Lamp, Brightness Adjustable
Filters	Blue
	Green
	Yellow
	Ground Glass

Optional Accessories		Item No.
Eyepiece	WF8x/18	A51.1002-8
	WF12.5x/15	A51.1002-12.5
	WF10x/18 with 0.1mm Micrometer & Cross Hair	A51.1007-10M
Objective	Infinity Plan Achromatic Objectives 20x/0.40/∞/- WD6.0mm	A5M.1035-20
	Infinity Plan Achromatic Objectives 40x/0.65/∞/- WD0.78mm	A5M.1035-40
	Infinity Plan Achromatic Objectives 50x/0.75/∞/- WD0.32mm	A5M.1035-50
	Infinity Plan Achromatic Objectives 80x/0.90/∞/- WD0.2mm	A5M.1035-80
	Infinity Plan Achromatic Objectives 100x/0.90/∞/0 WD0.7mm	A5M.1035-100
Polarizing	Simple Polarization Set	A5P.1004
Other	Specimen Presser For metallurgical specimen preparation	A5M.1010
